KB 91 - PowerConnect Java – Advanced PI filter configuration

direction

INBOUND,OUTBOUND

Filter on the direction of the PI message

INBOUND

interfacename

any string

Filter on the interface name of the PI message

testinterfacename

namespace

any string

Filter on the namespace of the PI message

testnamespace

messagetype

any string

Filter on the type of PI message

send

onlyfaultymessages

true, false

Track only PI messages that experience an error

true

receivername

any string

Filter on the receiver name of the PI message

testreceiver

receiverparty

any string

Filter on the receiver party of the PI message

testparty

sendername

any string

Filter on the sender name of the PI message

testsender

senderparty

any string

Filter on the sender party of the PI message

testparty

status

success, toBeDelivered, waiting, holding, delivering, systemError, cancelled

Filter on the status of the PI message

systemError

payload

true, false

Collect staged payload of the PI message

true

logs

true, false

Collect audit logs for the PI message

true

payloadversion

all, latest, comma separated list of versions

Collect specific version(s) of staged PI message payload

1,4

payloadlog

false, true

Collect logged payload of PI message

true

payloadlogversion

comma separated list of versions

Collect specific version(s) of logged PI message payload

1,4
